Eyebolt with Oval Link BS4278 Table2-China LG™



Description

Eyebolt with Oval Link BS4278 Table2 is screw in lifting attachments, with a male thread plus collar and eye at one end, machined from a solid steel drop forging.

These Eyebolts come attached with an oval link which are manufacture to BS 4279 Table 2 – 1984.

LG has produced Metric Thread Oval Link Eye bolts for many years and the price is competitive.

We have size: M8 , M10 , M12 , M14 , M18 , M20 , M22 , M24 , M30 , M36 , M42 , M45 , M48.



Technical & Feature

Technical NotesBS4278 table 2 Forgings: 1984 c
Surface FinishedSelf Colour / Electric Galvanised / Hot Dipped Galvanized
SizeM8 , M10 , M12 , M14 , M16 , M18 , M20 , M22 , M24 , M30 , M36 , M42 , M45 , M48
Safety Factor5:1
BrandLG™
OriginChina



Specification -Eyebolt with Oval Link BS4278 Table2

Eyebolt with Oval Link BS4278 Table2-China LG™

Part No.SizeSafe Working LoadDiameter ThreadDiameter LinkLink Inside LengthLink Inside WidthBase To Centre HeightThread LengthDiameter BaseWeight Each
Tonnesa (mm)b (mm)c (mm)d (mm)e (mm)f (mm)g (mm)kg
LGBS4278T208M80.181353242027390.33
LGBS4278T2010M100.15101353242027390.35
LGBS4278T212M120.2121353242027390.36
LGBS4278T214M140.3141353242027390.37
LGBS4278T216M160.4161353242027390.38
LGBS4278T218M180.7181353242027390.39
LGBS4278T220M201201353242027390.4
LGBS4278T222M221.3221563292332470.65
LGBS4278T224M241.6241563292332470.66
LGBS4278T230M302.5301980373041601.31
LGBS4278T236M3643624102463852752.69
LGBS4278T242M424.54230126584765945.31
LGBS4278T245M4554530126584765945.35
LGBS4278T248M486.34830126584765945.5



For any more help, e-mail our specialists at [email protected] for assistance.
