Stainless Steel Eye & Hook Turnbuckle European Type-China LG™
Description
Stainless Steel Eye & Hook Turnbuckle European Type-China LG™, also known as eye hook rigging screw.
This is our most economical turnbuckle. Stainless Steel Eye & Hook Turnbuckle (European Type) has a precision cast body and the eyes and hooks are formed and cold forged and the eyes are formed and then welded.
Stainless Steel Eye & Hook Turnbuckle European Type is generally used for straight or in line tensioning in conjunction with wire rope and chain assemblies when heavy duty straining and lifting applications are required.
China LG Supply carry a full line of turnbuckle hardware including jaw jaw, eye eye, hook hook and hook eye in various sizes from small turn buckles to large turnbuckles.
Turnbuckles are necessary equipment in marine rigging and architecture industries.
Technical & Feature
Technical Notes | European Type |
Material | Stainless steel 316 or stainless steel 304 |
Size | M5 M6 M8 M10 M12 M16 M20 |
Processing | Eye :Welding / Machining Body :Cast / Forge Hook :Stamping / Machining |
Surface Finished | Highly Polishing |
Tips | Corrosion Resistant |
Specification -Stainless Steel Eye & Hook Turnbuckle European Type
Part No. | Size | L(mm) | L1(mm) | D(mm) | S(mm) | WLL(kg) |
LG-SS-E-EH05 | M5 | 70 | 120 | 8 | 8 | 40 |
LG-SS-E-EH06 | M6 | 90 | 150 | 10 | 9 | 80 |
LG-SS-E-EH08 | M8 | 120 | 200 | 14 | 11 | 140 |
LG-SS-E-EH10 | M10 | 150 | 240 | 16 | 12 | 220 |
LG-SS-E-EH12 | M12 | 200 | 310 | 18 | 14 | 300 |
LG-SS-E-EH16 | M16 | 250 | 390 | 25 | 16 | 600 |
LG-SS-E-EH20 | M20 | 300 | 440 | 30 | 18 | 900 |
For any questions, e-mail our specialists at [email protected] for assistance.
