Stainless Steel Rigging Screw Toggle & Toggle-China LG™
Description
Stainless Steel Rigging Screw Toggle & Toggle-China LG™.
Stainless Steel Rigging Screws Toggle & Toggle can be used for a variety of applications.Sail boats and yachts, cable railing, and for shade sails.
Each turnbuckle body can be mixed and matched with jaw, eye and stud ends.
Each turnbuckle comes with a locking nut on each end. Not for overhead lifting.
AISI 316 stainless is a premium grade of stainless and is considered by many to be best in class.
316 stainless is corrosion resistant and very durable even in the harshest of conditions.
Technical & Application
Material | Stainless Steel AISI 316 |
Size | M6,M8,M10,M12,M16,M20 |
Processing | Body : Reduced Tube / Machining Toggle:Stamping/Machining/Welding |
Surface Finished | Highly Polishing |
Tips | Corrosion Resistant |
Specification -Stainless Steel Rigging Screw Toggle & Toggle
Part. No. | Thread Size | A (mm) | D (mm) | H (mm) | L1 (mm) | L2 (mm) | KG/100 | B.L.KG. |
LG-SSRS-TT-06 | M6 | 7 | 6 | 15 | 160 | 230 | 10 | 1250 |
LG-SSRS-TT-08 | M8 | 10 | 8 | 20 | 190 | 265 | 18 | 2350 |
LG-SSRS-TT-10 | M10 | 12 | 9 | 25 | 230 | 320 | 37.5 | 3500 |
LG-SSRS-TT-12 | M12 | 13 | 12 | 30 | 280 | 390 | 63 | 5100 |
LG-SSRS-TT-16 | M16 | 17 | 16 | 40 | 370 | 510 | 137 | 8000 |
LG-SSRS-TT-20 | M20 | 20 | 19 | 45 | 430 | 570 | 223 | 13000 |
For any help, pls e-mail our specialists at [email protected] for assistance.
