Stainless Steel Rigging Screw European Type Eye & Eye-China LG™

Description

Stainless Steel Rigging Screw European Type Eye & Eye-China LG™

Description

Stainless Steel Rigging Screw European Type Eye & Eye-China LG™,aslo known as eye and eye turnbuckles.

Stainless Steel Turnbuckle European Type Eye & Eye features a threaded eye at one end and a threaded eye at the other end.

It is ideal for catenary spans,marine rigging,fencing & architectural use.

Turnbuckles supply tension by adjusting the length for supporting rope,wire rope, and chain.

At its most basic,a turnbuckle is a couple of threaded eye bolts linked to its torso.However,the end fittings can also be a jaw or hook, depending on the specific need of the turnbuckle.

The instruments at each end (eye, jaw, hook) are adjustable and thread into the body frame.

Technical & Feature

Technical Notes	European Type
Material	Stainless Steel (AISI304 / AISI316)
Size	M5 M6 M8 M10 M12 M16 M20
Processing	Body ：Cast / ForgeEye ：Weld / Forge
Surface Finished	Highly Polishing
Tips	Corrosion Resistant

Specification — Stainless Steel Rigging Screw European Type Eye & Eye

Part No.	Size	L(mm)	L1(mm)	D(mm)	WLL(kg)
LG-SS-E-EE05	M5	70	120	8	170
LG-SS-E-EE06	M6	90	150	10	375
LG-SS-E-EE08	M8	120	200	14	575
LG-SS-E-EE10	M10	150	240	16	775
LG-SS-E-EE12	M12	200	310	18	1100
LG-SS-E-EE16	M16	250	390	25	2025
LG-SS-E-EE20	M20	300	440	30	2750
