Forged Turnbuckle with Flat ends
- Technology : Forged
- Material : ①Turnbuckle Body : Super Forged Carbon Steel (C1045#)
②Plain End : Super Forged Carbon Steel ( C1045#) - Finish : ROHS (CR3+ Plating )
- Details ：One Plain end with one Hole, Another end with two holes
Turnbuckle Eye & Eye US Fed Spec
- Meets federal specifications FF-T-791B, Type 1, Form 1, Class 4
- End fittings are quenched and tempered, bodies heat treated by normalizing.
- Sharp eye points bite into wood easily and quickly
- Manufactured from forged steel
Turnbuckle Hook & Eye US Fed Spec
- Proof Load is 2.5 times the Working Load Limit. Ultimate Load is 5 times the Working Load Limit.
- Meets specification FF-T-791b, Type 1, Form 1
- End fittings are Quenched and Tempered, bodies’ heat treated by normalizing.
- Hooks and eyes are forged with a greater cross sectional area that results in a stronger hook or eye with better fatigue properties.
Stainless Steel Swageless Eye Terminal
- Material: AISI 316
- Processing: Machining
- Finish: Highly Polishing
- Size – Wire: 3mm , 4mm , 5mm , 6mm , 8mm , 10mm , 12mm , 14mm , 16mm
Turnbuckle Jaw & Jaw US Fed Spec
- Technical Notes: US Federal Specification
- Material: Superior Carbon Steel
- Safety Factor: Proof tested to 2 x WLL and Minimum Break Force is 5 x WLL.
- Processing: Drop Forged / Machining / Quenched and Tempered
- Finish: Hot Dipped Galvanized / Electric Galvanized
Turnbuckle Jaw & Eye US Fed Spec
- Forged, heat-treated steel
- Designed to ASTM-F 1145 Specifications
- Locking nuts available
- Excellent Fatigue Rating
- 5:1 Factor of Safety
Turnbuckle Hook & Hook US Fed Spec
- Meets federal specifications FF-T-791B, Type 1, Form 1, Class 4
- End fittings are quenched and tempered, bodies heat treated by normalizing.
- Hot Dipped Galvanized / Electric Galvanized
- Manufactured from forged steel
JIS Turnbuckle Forged Steel Frame Type
- Technical Notes: JIS Type
- Material: Superior Mild Steel
- Processing: Drop Forged
- Finish: Electric Galvanized / Hot Dipped Galvanized
Stainless Steel Swaged Jaw Terminals
- Made by 304 or 316 Stainless Steel
- Stamping / Machining / Welding
- High specification polished
- High corrosive resistant
Stainless Steel Wire Rope Swage Toggle Jaw Terminals, European Type
- Made by 304 or 316 Stainless Steel
- Removable clevis pin
- High specification polished
- High corrosive resistant
Stainless Steel Swage Eye Terminal
- Made by 304 or 316 Stainless Steel
- High specification polished
- Ideal for balustrading & suspended systems.
- These need to be Hydraulically Swaged onto your Steel Wire Rope
Swageless Lag Screw Stud Terminal
- Processing: Machining
- Finish: Highly Polishing
- Size – Wire: 1/8″ , 5/32″ , 3/16″ , 1/4″
Stainless Steel Swageless Deck Toggle
- Material: Stainless Steel (AISI 316)
- Finish: Highly Polishing
- Processing: Machining
- Size – Wire: 1/8″ , 5/32″ , 3/16″ , 1/4″
Stainless Steel Cable Railing Deck Toggle
- Made by 304 or 316 Stainless Steel
- Polished Finished
- Holds up against corrosion
- Suitable for outdoor or indoor and has an excellent shine and radiance
Stainless Steel Swageless Stud Thread Terminal
- Material: Stainless Steel
- Finish: Highly Polishing
- Processing: Machining
- Size – Wire: 3mm , 4mm , 5mm , 6mm , 8mm , 10mm , 12mm , 14mm , 16mm
Stainless Steel Square Head Bow Shackle
- Technical Notes：European Type
- Material：AISI 304/316
- Processing：Forged / Stamping
- Finish：Highly Polishing / Electrophoretic coating
Wire Toggle YOYO Stainless Steel
- Stainless steel AISI 304 / AISI 316 – Highly Polishing.
- Processing : Welded / Cast
- For wire Dia. : 20mm
Wire Toggle YOYO Welded Steel
- Superior Mild steel – Self-color.
- Processing : Welded / Cast
- For Wire Dia. : 16mm , 25mm
Chain Toggles Welded Steel Spacer
- Superior Mild steel – Self-color.
- Processing : Welded / Cast
- For Wire Dia. : 10mm , 13mm
Chain Toggles Heavy Type Spacer Welded Steel
- Superior Mild steel – Self-color.
- Processing : Welded / Cast
- For Wire Dia. : 10mm , 13mm
